281637 282049 282051 Flow sensor For Medical ventilators

281637 282049 282051 Flow sensor For Medical ventilators
281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators

Büyük resim :  281637 282049 282051 Flow sensor For Medical ventilators

Ürün ayrıntıları:
Menşe yeri: Amerika
Model numarası: 281637 282049 282051
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 adet
Fiyat: pazarlık edilebilir
Ambalaj bilgileri: Standart ambalaj
Teslim süresi: 5-8 iş günü
Ödeme koşulları: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Yetenek temini: 5000 pcs

281637 282049 282051 Flow sensor For Medical ventilators

Açıklama
Akış aralığı: 0 ila 180 l/dk (kısa vadeli 260 l/dk) Ölü alan: <11 ml (fonksiyonel)
Rezistans: Tam akış aralığında <0.027 cmh2o/(l/dk) (-180 l/dk ila 180 l/dak) Sıcaklık: Çalışma: -20 ° C ila 50 ° C (-4 ° F ila 122 ° F)
Vurgulamak:

medical ventilator flow sensor

,

air flow sensor for ventilators

,

medical air flow sensor with warranty



                                           281637 282049 282051 Flow sensor For Medical ventilators





Product Overview:

The 281637 is a compact, industrial-grade gas sensor designed for reliable detection of specific target gases (confirm target gas with manufacturer, e.g., carbon monoxide, methane, volatile organic compounds, or oxygen). It adopts semiconductor (metal oxide) or electrochemical sensing technology (depending on target gas) to deliver fast response, low power consumption, and stable long-term performance. Typical applications include industrial safety monitoring (e.g., factory leak detection), indoor air quality (IAQ) management, smart home safety systems, and portable gas detectors.



No.

Component/Parameter Category

Description

Specification/Details

Material

Remarks

1 Connector Ventilator side OD15 PSU -
2 Tubing - - PVC -
3 Connectors for Tubing Differential pressure measurement - PSU -
4 Direction Index - - - -
5 Individual Serial Number - - - -
6 Connector Patient side OD22/ID15 PSU -
7 Flap - - PET -
- Technical Performance Flow range 0 to 180 l/min (short term: 260 l/min) - -
- Technical Performance Dead space < 11 ml (functional) - -
- Technical Performance Resistance < 0.027 cmH₂O/(l/min) over the complete flow range (-180 l/min to 180 l/min) - -
- Technical Performance Weight - Approx. 14 g (without tubes)
- 68 g (with 188 cm tubes)
- 89 g (with 260 cm tubes)
- 110 g (with 330 cm tubes)
- -
- Material Compliance Material standards 1. Complies with ISO 10993-1:2009 (biocompatibility)
2. Complies with Directive 2011/65/EU (RoHS)
3. No natural rubber latex, DEHP, or BPA
- Ensures safety for medical use
- Accuracy (Calibrated Flow Sensor) Volume-related parameters (HAMILTON ventilators) - HAMILTON-C1/T1/MR1/C2/C3/C6: ± 10% or ± 10 ml (whichever is greater)
- HAMILTON-G5/S1: ± 15% or ± 20 ml (whichever is greater)
